The other problem, creep, refers to a gradual change in the length of the gauge element which does not correspond to any change of strain in the material that is being measured. This also should be very small, of the order of 0. Both hysteresis and creep increase noticeably as the operating temperature of the gauge is raised. A load cell is a force transducer that converts force or weight into an electrical signal. Basically, the load cell uses a set of strain gauges, usually four connected as a Wheatstone-bridge circuit. The output of the bridge circuit is a voltage that is proportional to the force on the load cell.

This output can be processed directly, or digitized for processing. Though the principles of the method are quite ancient, its practical use had to wait until suitable lasers and associated equipment had been developed, along with practicable electronic methods of reading the results. When waves meet and are in phase a , the amplitudes add so that the resultant wave has a larger amplitude. If the waves are in antiphase b , then the resultant is zero or a wave of small amplitude. All waves exhibit interference Figure 1.

When two waves meet and are in phase peaks of the same sign coinciding , then the result is a wave of greater amplitude, a reinforced wave. This is called constructive interference. If the waves are in opposite phase when they meet, then the sum of the two waves is zero, or a very small amplitude of wave, and this is destructive interference.

The change from constructive to destructive interference therefore occurs for a change of phase of one wave relative to another of half a cycle. If the waves are emitted from two sources, then a movement of one source by a distance equal to half a wavelength will be enough to change the interference from constructive to destructive or vice versa. If the waves that are used have a short wavelength, then the distance of half a wavelength can be very short, making this an extremely sensitive measurement of change of distance.

The wavelength of red light is about nm, i. This method would have been used much earlier if it were not for the problem of coherence. The set-up of laser and glass plates is shown in a. The light is therefore the sum of all the pulses from the individual atoms, rather than a continuous wave. The laser has completely changed all this. The laser gives a beam in which all the atoms that contribute light are oscillating in synchronization; this type of light beam is called coherent.

The interferometer makes use of both of these properties as illustrated in Figure 1. Since this is a light beam, this implies that the illumination on the screen will change between bright and dark. The interferometer is often much too sensitive for many purposes. This is the average distance over which the light remains coherent, and is usually at least several metres for a laser source. This change of phase can be used to detect small movements by using the type of arrangement shown in Figure 1.

When a ray of light passes from an optically dense highly refractive material into a less dense material, its path is refracted away from the original direction a and more in line with the surface. The sensor must be calibrated over its whole range, because there is no simple relationship between the amount of movement and the amount by which the light is delayed.

For a solid, the amount of stress would be calculated, either from knowledge of force and area of cross-section, or from the amount of strain. Where the stress is exerted on a wire or girder, the direct calculation of stress may be possible, but since strain can be measured by electronic methods, it is usually easier to make use of the relationship shown in Table 1. Young's modulus is a quantity that is known for each material, or which can be measured for a sample of material. The stress is stated in units of 12 Table 1.

The measurement of pressure in liquids and gases covers two distinct ranges. Pressure in liquids usually implies pressures greater than atmospheric pressure, and the methods that are used to measure pressures of this type are similar for both liquids and gases. For gases, however, it may be necessary also to measure pressures lower than atmospheric pressure, in some cases very much lower than atmospheric pressure.

The best-known principle is that of the aneroid barometer, illustrated in Figure 1. The diaphragm is acted on by the pressure that is to be measured on one side, and a constant usually lower pressure on the other side. In the domestic version of the barometer, the movement of the diaphragm is sensed by a system of levers which provide a pointer display of pressure.

For electronic measurement, the diaphragm can act on any displacement transducer and one well-suited type is the capacitive type, illustrated in Figure 1. Reducing the spacing between the diaphragm and the backplate will increase the capacitance, in accordance with the formula shown in Figure 1. The domestic barometer uses an aneroid capsule with a low pressure inside the sealed capsule. This is an inside-out arrangement as compared to the domestic barometer. The pressure to be measured is applied inside the capsule, with atmospheric air or some constant pressure applied outside. The formula relating capacitance to spacing is shown in b.

The movement of the diaphragm causes considerable changes in the reluctance of the magnetic path, and so in the inductance of the coil. This provides a very sensitive detection system, and one which is fairly easy to calibrate. Although the thin metal corrugated diaphragm makes the device suitable only for detecting pressures of about atmospheric pressure, the use of a thicker diaphragm, even a thick steel plate, can permit the method to be used with very much higher pressures. For such pressure levels, the sensor can be made in the form of a small plug that can be screwed or welded into a container.

The smaller the cross-section of the plug the better when high pressures are to be sensed, since the absolute amount of force is the product of the pressure and the area of cross-section. The materials used for the pressure-sensing plate or diaphragm will also have to be chosen to suit the gas or liquid whose pressure is to be measured. For most purposes, stainless steel is suitable, but some very corrosive liquids or gases will require the use of more inert metals, even to the extent of using platinum or palladium. The method can also be used for gases, and for a range of pressures either higher or lower than atmospheric pressure.

Another transducing method uses a piezoelectric crystal, usually of barium titanate, to sense either displacement of a diaphragm connected to a crystal, or pressure directly on the crystal itself. As explained earlier, this is applicable more to short duration changes than to steady quantities. For a very few gases, it may be possible to expose the piezoelectric crystal to the gas directly, so that the piezoelectric voltage is proportional to the pressure change on the crystal. For measurements on liquids and on corrosive gases, it is better to use indirect pressure, with a plate exposed to the pressure which transmits it to the crystal, as in Figure 1.

This type of sensor has the advantage of being totally passive, with no need for a power supply to an oscillator and no complications of frequency measurement. Piezoresistive, piezoelectric, and capacitive pressure gauges can be fabricated very conveniently using semiconductor techniques. Piezoelectric and capacitive pressure-sensing units can be created using the same methods. Pressures that are only slightly lower than the atmospheric pressure of around kPa can be sensed with the same types of devices as have been described for high pressures. Pressure sensors and transducers for this range are more often known as vacuum gauges, and many are still calibrated in the older units of millimetres of mercury of pressure.

The conversion is that 1 mm of mercury is equal to The high-vacuum region is generally taken to mean pressures of 10 3 mm, of the order of 0. Of some 20 methods used for vacuum measurement, the most important are the Pirani gauge for the pressures in the region 1 mm to 10 3 mm about Pa to 0. A selection of measuring methods is illustrated in Table 1. All vacuum gauge heads need recalibration when a head is replaced. The Pirani gauge, named after its inventor, uses the principle that the thermal conductivity of gases decreases in proportion to applied pressure for a wide range of low pressures.

The gauge Figure 1. Gauge type Pressure range Pa Diaphragm Manometer Pressure balance Radioactive ionization gauge Compression gauge Viscosity gauge Pirani gauge Thermomolecular gauge Penning gauge Cold-cathode magnetron gauge Hot-cathode ionization gauge High-pressure ionization gauge Hot cathode gauge Modulator gauge Suppressor gauge Extractor gauge Bent beam gauge Hot-cathode magnetron gauge 10 5 10 5 1 10 2 10 6 10 6 10 3 10 7 10 7 10 8 10 5 10 4 10 7 10 8 10 9 10 10 10 11 10 11 to to to to to to to to to to to to to to to to to to 10 2 10 3 10 5 10 5 10 3 10 3 10 4 10 1 10 1 10 2 1 10 10 2 10 2 10 2 10 2 10 2 10 2 Figure 1.

Commercially available Pirani gauges, such as those from Leybold, are robust, easy to use, fairly accurate, and are not damaged if switched on at normal air pressures. The ionization gauge operates by using a stream of electrons to ionize a sample of the remaining gas in the space in which the pressure is being measured. The positive gas ions are then attracted to a negatively charged electrode, and the amount of current carried by these ions is measured. The range of the gauge is to about 10 7 mm 0. The most serious problem in using an ionization gauge is that it requires electron emission into a space that is not a perfect vacuum.

If this can be done, then the ionization gauge can have a long and useful life. With a constant high current of electrons to the anode, positive ions from the remaining gas are attracted to the grid and the resulting grid current is measured and taken as proportional to gas pressure. A common variation on the ionization method is the Penning gauge, which uses electron emission from a point a cold-cathode emitter.

Catalog Chapter

If the electron beam is taken through a longer path, more atoms can be bombarded, and more ions generated from a given volume of gas, and so the sensitivity of the device is greatly increased. This is the magnetron principle, used in the magnetron tube to generate microwave frequencies by spinning electrons into a circular path that just touches a metal cavity, so that the cavity resonates and so modulates the electron beam.

Gauges of this type can be used down to very low pressures, of the order of 10 11 Pa. On the other end of the pressure range, a radioactive material can be used as a source of ionization, and this allows measurements up to much higher ranges of pressure, typically up to 10 5 Pa. The piezoelectric device used for pressure sensing is also a useful transducer, and can be used in either direction.

The conversion of energy from an electrical form into stress can be achieved by the magnetically cored solenoid, as illustrated in Figure 1. The amount of force can be large, so that stress can be exerted causing strain on a solid material. If the core of the solenoid is mechanically connected to a diaphragm, then the force exerted by the core can be used to apply pressure to a gas or a liquid.

In general, though, there are few applications for electronic transducers for strain or pressure and the predominant use of devices in this class is as sensors. Chapter 2 Position, direction, distance and motion 2. In this chapter we shall look at the methods that are used to measure direction and distance so that position can be established either for largeor small-scale ranges of movement. For a three-dimensional location, three axes, labelled x, y and z, can be used. Figure 2. For a three-dimensional location, an additional angle is used. Calculate the position of the star at the time of your observation, using the Almanac.

From this position calculation, calculate for each star you have observed what altitude and azimuth direction you should have observed. Plot each offset on a chart as a line of position. Find your true position as the point where several lines of position cross. Starting with the most ancient method, observation of stars, otherwise known as Celestial navigation, depends on making precise angle measurements.

Sensors and transducers fuse with AI and fog computing - Electronic Products

The basic two-dimensional requirements are a time measurement and tables of data. The simplest form of celestial navigation is the observation of local noon. Navigation by the local noon method is simple, but it is not necessarily always available, and although it has been the mainstay of navigation methods in the past, it was superseded several centuries ago by true celestial navigation, which relies on making a number of observations on known stars. The advantage of using stars is that you do not have to wait for a time corresponding to local noon. The process is summarized in Table 2.

The size and direction of this correction can be obtained from tables of magnetic constants the magnetic elements that are published for the use of navigators. The drift speed and direction of the magnetic north pole can be predicted to some extent, and the predictions are close enough to be useful in fairly precise navigation in large areas on the Earth's surface.

The principle is illustrated in Figure 2. Since the electrons are negatively charged, the top of the slab is negative and the bottom positive. If the main carriers are holes, the voltage direction is reversed.

By using an analogue to digital converter for angular rotation, the direction can be read out in degrees, minutes and seconds. Magnetic compasses served the Navy well in the days of wooden ships, and when iron later, steel construction replaced wood, magnetic compasses could still be used provided that the deviation between true magnetic north and apparent north distorted by the magnetic material in the ship could be calculated and allowed for, using deviation tables.

This compass model was superseded, in , by the Sperry type of gyrocompass. Full acceptance of gyrocompasses did not occur until errors caused by the ships' movement could be eliminated. The magnetic portion of the wave will induce signals in a coil, but the phase of these signals depends on the direction of the transmitter. By combining the signals from the two aerials, and turning the coil, the direction of the transmitter can be found as the direction of maximum signal.

Gyrocompass design was considerably improved for use in air navigation in World War II. The gyrocompass has no inherent electrical output, however, and it is not a simple matter to obtain an electrical output without placing any loading on the gyro wheel. Laser gyroscopes making use of rotating light beams have been developed, but are extremely specialized and beyond the scope of this book. Radio has been used for navigational purposes for a long time, in the form of radio beacons that are used in much the same way as light beacons were used in the past.

The classical method of using a radio beacon is illustrated in Figure 2. The signal from the coil aerial is at maximum when the axis of the coil is in line with the transmitter, and the phase of this maximum signal will be either in phase with the signal from the vertical whip aerial or in antiphase, depending on whether the beacon transmitter is ahead or astern of the coil. By using a phase-sensitive receiver that indicates when the phases are identical, the position of maximum signal ahead can be found, and this will be the direction of the radio beacon.

The original Watson-Watt system used multiple-channel reception with two dipoles, arranged to sense directions at right angles to each other and a single whip aerial connected to separate receivers. A later improvement used a single channel, and modern methods make use of digital signal processing to establish direction much more precisely. A geostationary satellite is one whose angular rotation is identical to that of the Earth, so that as the Earth rotates the satellite is always in the same position relative to the surface of the planet.

The navigation satellites are equipped with transponders that will re-radiate a coded received signal. At the surface, a vessel can send out a suitably coded signal and measure the time needed for the response. This time can be very short, of the order of microseconds or less, so that the duration of the wave pulse must also be very short, a small fraction of the time that is to be measured. Both radar and sonar rely heavily on electronic methods for generating the waveforms and measuring the times, and although we generally associate radar with comparatively long distances, we should remember that radar intruder alarms are available whose range is measured in metres rather than in kilometres.

The time required for a pulse of microwave signal to travel to the target and back is displayed in the form of a distance on a cathode ray tube. The air pressure, however, alters with other factors such as humidity, wind-speed and temperature, so that pressure altimeters are notoriously unreliable.

Even if such an altimeter were to give a precise reading, the height that it measures will either be height above sea-level or the height relative to the altitude of the place in which the altimeter was set, rather than true height. It is, in fact, remarkable that air travel ever became a reality with such a crude method of height measurement. Position measurement on a smaller scale e. In this case, we shall start with the sensors for short distance movements, because for motion over large distances the distance travelled will generally be calculated by comparing position measurements rather than directly.

Sensors for small distances can make use of resistive, capacitive or inductive transducers in addition to the use of interferometers see Chapter 1 and the millimetrewave radar methods that have been covered earlier. The methods that are described here are all applicable to distances in the range of a few millimetres to a few centimetres. Beyond this range the use of radar methods becomes much more attractive.

A simple system of distance sensing is the use of a linear in the mechanical sense potentiometer Figure 2. The output can be displayed on a meter, converted to digital signals to operate a counter, or used in conjunction with voltage level sensing circuits to trigger some action when the object reaches some set position.

The main objections to this potentiometric method are: that the range of movement is limited by the size of potentiometers that are available although purpose-built potentiometers can be used , and that the friction of the potentiometer is an obstacle to the movement.

The precision that can be obtained depends on how linear in the electrical sense the winding can be made, and 0. The advantage of this type of sensor is that the output can be a steady DC or AC voltage that changes when the displacement changes. A change in the position of the moving plate will cause the voltage between this plate and the centre tap of the transformer to change phase, and this phase change can be convened into a DC output from the phase-sensitive detector.

An alternative that is sometimes more attractive, but often less practical, is the use of a capacitive sensor. The type of circuit arrangement is illustrated in Figure 2. Because the capacitance between plates is inversely proportional to plate spacing, this method is practicable only for very short distances, and is at its most useful for distances of a millimetre or less.

An alternative physical arrangement of the plates is shown in Figure 2. The most commonly used methods for sensing distance travelled on the small scale, however, depend on induction. The basic principle of induction methods is illustrated in Figure 2. If one coil is supplied with an AC signal, then the amplitude and phase of a signal from the second coil depends on the position of the ferromagnetic core relative to the coils. The range of movement for this type can be considerably greater than for the previous type. An AC voltage is applied to one coil, and the position of the core determines how much will be picked up by the other coil.

In addition, the shape of the graph means that even if the range is restricted the output is never linearly proportional to the distance. Movement of the core alters the voltage levels and phases of the voltages across the outer coils, and these voltages can be converted into DC by the phase-sensitive detector. The principle is illustrated by the circuit diagram shown in Figure 2. The other two coils are connected to a phase-sensitive detector, and as a core of ferromagnetic material moves in the coil axis, the output from the detector will be proportional to the distance of the core from one end of the coils.

As the name suggests, the output from the phase-sensitive detector will be fairly linearly proportional to distance, and there are considerable advantages as compared to other types of distance sensors, as follows. Virtually zero friction, since the core need not be in contact with the coils, and so no wear. Linear output. Very high resolution, depending mainly on the detector. Good electrical isolation between the core and the coils. No risk of damage if the core movement is excessive. Strong construction that is resistant to shock and vibration.

The performance of the AC types is always superior, but in some systems where, because of lack of space, no separate AC supply can be provided, the DC type must be used. Typically, a frequency of 5 kHz is used for the AC drive. Because of the seven advantages listed above, the LVDT has superseded most other types of distance sensors. For very small distances, the strain gauge see Chapter 1 can be used; laser interferometers are applicable when very precise changes must be sensed, and radar methods are used for longer distances.

One peculiar advantage of the laser interferometer is that its output can readily be converted to digital form, since it is based on the counting of wavepeaks. Most sensors give analogue outputs, and where a sensor is described as having a digital output, this usually implies that an analogue to digital conversion has been carried out. The interferometer is one of the few sensors which is capable of providing a genuinely digital output. Another is the linear digital encoder, and since digital methods are of everincreasing importance in measurement and control, a description of this device in detail is appropriate here.

The simplest form of encoder of this type is optical, and the principle is illustrated in Figure 2. A glass strip is printed with a pattern of the form shown, using large blocks rather than the more practical lines, alternately opaque and transparent. The next strip in turn has bars that are twice the width of its predecessor and so on. The number of strips determines the number of binary digits in the output and the number of increments of position that can be detected.

The optical linear encoder is read by using a sensor for each strip or track. Moving the glass strip between a light source and a set of photocells will result in outputs from each photocell that will make up a binary number. The main problem of using binary code with this system is that incorrect readings can be obtained when the position of the slide is such that sections overlap the photocells. The resolution is equal to the width of the units mark.

The photocells must be placed almost in contact with the encoder slide, and with suitable light shielding to ensure that stray light does not cause false responses. One problem that arises with optical linear or angular encoders is the suitability of the coding system. The usual binary number system is often termed code, in recognition of the fact that each digit place represents a doubling or halving of the value of the adjacent place.

This can mean that some changes of number can involve changes in more than one of the digits. Denary binary Grey code Denary binary Grey code 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 change from to , in which each of four digits has changed simply to indicate a value change of just one unit. For this reason, another code, the Grey code illustrated in Table 2. ICs exist which will convert Grey code into normal binary, so that arithmetic can be carried out on the numbers if needed. For some applications, conversion may not be necessary. The linear digital encoder systems provide a set of binary digital signals directly, but since this requires a slide which is very precisely printed and which will use one detector for each binary digit, less direct conversion methods are often used.

Nuclear Physics: Exploring the Heart of Matter

A slide using only a single set of equally spaced markings can be used in conjunction with a two-phase pick-up system to provide pulse signals whose phasing can be used to indicate direction and whose count indicates distance moved. A system of this type has only a single output to a counter with a second connection if direction is to be sensed , and the counter will then convert into binary code. This type of system is considered more fully under the heading of Rotation later in this chapter.

Another optical method that is particularly useful for small displacements, particularly vibration amplitudes, is the optical grating method whose principles are illustrated in Figure 2.


  • Applications and Techniques in Information Security: 6th International Conference, ATIS 2016, Cairns, QLD, Australia, October 26-28, 2016, Proceedings;
  • Physiological Transducers?
  • SENSORS AND TRANSDUCERS, 3RD EDITION.
  • Chapter Smart Transducers (Sensors or Actuators), Interfaces, and Networks | Engineering;

The two slides each have identical thin line patterns printed on them. When one slide moves relative to the other, the amount of light passing through varies considerably depending on the relative positions of lines and spaces in the two slides. Large movements are read in terms of the number of complete waves of output from the photocell, small movements in terms of the amplitude of the signal. The mass that is used as part of an acceleration sensor must therefore be supported in the vertical plane, and the type of support that is used will depend on whether accelerations in this plane are to be measured.

This in turn will stretch or compress the spring, and the amount of this displacement can be measured by any of the usual methods, usually by an LVDT. If the acceleration to be measured is always in a horizontal direction, then the mass can be supported on wheels, ball bearings or air-jets, depending on the sensitivity that is required. Since a force on the mass is to be sensed, the mass will also have to be coupled to a sensor. The method of sensing force is to measure the displacement of the mass against the restoring force of a spring, so that the outline system for a horizontal accelerometer is as sketched in Figure 2.

The weight of the mass is supported on ball bearings, and the mass is held in the horizontal plane by springs. In Figure 2. The amount of linear movement will be proportional to the force, so that any sensor for linear displacement can be used to give an output that is proportional to acceleration. Suitable transducers include potentiometers, capacitive distance gauges, inductive gauges and LVDTs for the larger ranges of movement that are possible.

Sensors for acceleration that use this spring and displacement principle are generally intended for the measurement of very small accelerations, usually in one plane. If only a single dimensional acceleration can be measured, the acceleration in any other direction will produce a false reading, equal to the component of acceleration in that direction. If the mass can be supported in a cradle of springs and three displacement sensors connected, one for each axis of motion two horizontal and one vertical , then the outputs can be used to compute the magnitude and direction of an acceleration that can be in any direction.

A strain-gauge sensor can be connected to an inertial mass, with or without spring suspension in order to measure acceleration, but the most common type of accelerometer uses an inertial mass coupled to a piezoelectric crystal. The principle is that some crystalline materials such as quartz silicon oxide , Rochelle salt and barium titanate are composed of charged particles ions which do not move uniformly when the crystal is stressed. The voltage is proportional to the strain of the crystal and can be very large, of the order of kilovolts for some ceramic crystal types, if the strain of the crystal is large.

The use of an inertial mass bonded to a piezoelectric crystal therefore provides an accelerometer that requires no springs or special supports for the mass. It is even possible to obtain two-dimensional signals from one crystal, and the system will respond to a very wide range of accelerations. The snag is that the piezoelectric crystal is, from the circuit point of view, a capacitor, and the signal is in the form of a charge. The connection of a resistance to the contacts on the faces of the crystal will therefore allow this capacitance to discharge with a time constant equal to CR seconds, where C is the capacitance between the crystal faces in mF and R is the resistance between the faces in MO.

As it happens, most accelerations are not sustained. The only steady and constant value of acceleration that we normally encounter is the acceleration of gravity, and most of our acceleration measurements are on accelerations that are caused by short-duration forces, such as those encountered when one object hits another. To put this into perspective, an acceleration of only 1 g for 10 s corresponds to falling a distance of about m in a vacuum.

In general, unless you are working with propulsion systems for outer space, the measurement of small accelerations that are applied for long periods will be of no practical interest. When an accelerometer of any type produces an electrical output, this output can be used for computing other quantities. One of these quantities is speed or, more correctly, velocity because an acceleration exists when a change of direction or a change of speed, or both, take place.

The relationship between speed or velocity value and acceleration is shown in Figure 2. A second integration of the voltage output the speed output will produce a signal proportional to distance, so that this quantity can also be found by using an analogue computing action on the output of the accelerometer. If the starting point of the motion is rest no starting speed , then no constants need to be fed in.

If quantities are expressed in digital terms, then a digital computer can be used to calculate the integral values. The quantities that are used to measure rotation correspond to the quantities that are used in the measurement of linear motion in such a way that the same types of equations can be used, substituting the rotational quantities for the linear ones.

To convert from degrees to radians, divide the angle in degrees by If the rotating object is a wheel and is in contact with a surface, then Figure 2. The sensors for angular motion are also very closely related to those that are used for linear motion. For sensing and measurement purposes only a minimum of power must be used, so that a miniature AC generator called the tacho-generator is normally used. The construction 42 Figure 2. The frequency of the output signal is proportional to the revolutions per second of the shaft that is coupled to the tacho, so that a frequency-sensitive detector can be used to give a DC output proportional to angular frequency.

The tacho can be used over a wide range of angular velocity values, and if the frequency detector is reasonably linear then the readings can be of high precision. The drawback for some applications is the need to make a mechanical coupling between the tacho and the revolving shaft. A drag system involves a frictional coupling between the rotating shaft and some object that is restrained and whose displacement can be measured.

One version of this is the drag cup, whose principle is illustrated in Figure 2. The motion of the shaft is communicated by the viscosity of the oil to a turning force torque on the cup, and the displacement of the cup against the spring is measured by the sensor. Since displacement should be proportional to torque, which in turn should be proportional to rotational speed of the shaft, output from the sensor is proportional to rotational speed over a small range of speeds. The range is small because the assumption that torque is proportional to rotational speed holds good for only a small range of speeds, and the system is best suited for slow rotations.

Another version of this method that is much more versatile is the magnetic disc type. The method can be converted to electrical output by dispensing with the pointer and mounting the cup and its retaining spring on to the shaft of a potentiometer. This has been extensively used in car speedometers, and can be adapted to electronic measurement by replacing the disc and its mountings by a sensing coil.

This is the scheme that has been used for many years for car speedometer heads, and it operates best at a medium range of angular speeds. One particular advantage is that no contact is needed, though there must not be any metal between the magnet and the disc. A piezoelectric pulse can be operated, as indicated in Figure 2. The disadvantages are that there is only one pulse per revolution, and that the contact between cam and crystal causes a frictional drag on the rotation of the shaft.

In addition, the friction on the shaft is fairly large compared to the alternative system of magnetic pulsing. The magnetic pulse system uses a permanent magnet mounted on a wheel or shaft and passing over a coil at one part of the revolution. As the magnet moves, a voltage is induced in the coil, so providing a signal for each revolution.

Angular displacement measurement methods fall into two groups: those for very small angular displacements that are temporary, and those for large displacements. Temporary small displacements are of a degree or less, and the shaft or other rotating object returns to its original position following the rotation. Such small displacements are sensed by variants of the methods used for small linear displacements, such as capacitive, strain gauge and piezo sensors. The rotary digital encoder can be used to provide a direct digital output, using a wheel of the form shown in Figure 2.
